TZV2Z100A110R00
RoHS
RoHS compliant
RoHS compliantPackage V
Category Capacitors / Trimmers, Variable Capacitors
Description
V TZV2 25V 10pF 100% 0.126Lx0.091W 3.20mmx2.30mm
PDF
/
Inventory: 1146
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 2.3mm
Height Seated (Max) 0.057 1.45mm
Height 1.4478mm
Technical
Capacitance Range 3pF~10pF
Adjustment Type Top
Q @ Freq 500 @ 1MHz
Voltage 25V
Size Code 1209
Dielectric NP0
Depth 3.2mm
Packing Method TR, 7 INCH
Voltage - Rated DC 25V
Capacitance 10pF
HTS Code 8532.30.00.10
Additional Feature PERCENTAGE TOLERANCE ON C_MAX IS 0/+100
Terminal Finish TIN/GOLD
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Pbfree Code yes
Feature General Purpose
JESD-609 Code e3/e4
Tolerance 100%
Size / Dimension 0.126Lx0.091W 3.20mmx2.30mm
Series TZV2
Packaging Tape & Reel (TR)
Operating Temperature -25°C~85°C
Physical
Dielectric Material Ceramic
Terminal Shape WRAPAROUND
Package / Case V
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status TO BE DISCONTINUED (Last Updated: 2 weeks ago)
