TZC3Z030A110B00
RoHS
RoHS compliant
RoHS compliantPackage SMD/SMT
Category Capacitors / Trimmers, Variable Capacitors
Description
SMD/SMT VARIABLE CAPACITOR TZC3 100V 3pF 50% 300ppm/C
PDF
/
Buying Options
Total Price: USD $0.83
Unit Price: USD $0.831066
≥1 USD $0.831066
≥200 USD $0.332164
≥500 USD $0.321661
≥1000 USD $0.315096
Inventory: 2781
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 3.2mm
Height Seated (Max) 0.067 1.70mm
Height 1.6002mm
Technical
Adjuster Orientation VERTICAL
Capacitance Range 1.4pF~3pF
Adjustment Type Top
Q @ Freq 300 @ 1MHz
Test Frequency 1MHz
Size Code 1812
Capacitor Type VARIABLE CAPACITOR
Voltage - Rated AC 100V
Depth 4.5mm
Voltage - Rated DC 100V
Capacitance 3pF
HTS Code 8532.30.00.10
Additional Feature PERCENTAGE TOLERANCE ON C_MAX IS 0/+50
Color Brown
Terminal Finish Silver (Ag)
Temperature Coefficient 300 ppm/°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature General Purpose
JESD-609 Code e4
Tolerance 50%
Size / Dimension 0.177Lx0.126W 4.50mmx3.20mm
Series TZC3
Packaging Bulk
Operating Temperature -25°C~85°C
Physical
Dielectric Material Ceramic
Terminal Shape WRAPAROUND
Package / Case SMD/SMT
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status TO BE DISCONTINUED (Last Updated: 1 month ago)
