TZB4Z030EA10B00
RoHS
RoHS compliant
RoHS compliantPackage /
Category Capacitors / Trimmers, Variable Capacitors
Description
TZB4 VARIABLE CAPACITOR Trimmer Capacitor 0.177Lx0.157W 4.50mmx4.00mm 1.4pF~3pF 100V
PDF
/
Buying Options
Total Price: USD $1.24
Unit Price: USD $1.240691
≥1 USD $1.240691
≥200 USD $0.494963
≥500 USD $0.479209
≥1000 USD $0.471331
Inventory: 7077
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Surface Mount YES
Terminal Shape GULL WING
Dielectric Material Ceramic
Technical
Operating Temperature -25°C~85°C
Packaging Bulk
Series TZB4
Size / Dimension 0.177Lx0.157W 4.50mmx4.00mm
JESD-609 Code e3
Feature General Purpose
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin (Sn)
Voltage - Rated 100V
Additional Feature PERCENTAGE TOLERANCE ON C_MAX IS 0/+50
HTS Code 8532.30.00.10
Capacitor Type VARIABLE CAPACITOR
Rated (DC) Voltage (URdc) 100V
Size Code 2816
Positive Tolerance 50%
Q @ Freq 300 @ 1MHz
Adjustment Type Bottom Adjustment
Capacitance Range 1.4pF~3pF
Adjuster Orientation VERTICAL
Dimensions
Height Seated (Max) 0.126 3.20mm
Length 7mm
Width 4mm
Compliance
RoHS Status ROHS3 Compliant
