TZB4R200EA10R01

Murata Electronics
RoHS
RoHS RoHS compliant
Package SMD/SMT
Category Capacitors / Trimmers, Variable Capacitors
Description TZB4 VARIABLE CAPACITOR SMD/SMT Trimmer Capacitor 0.177Lx0.157W 4.50mmx4.00mm 50% 4.5pF~20pF 100V
PDF
/
Buying Options
Total Price: USD $0.96
Unit Price: USD $0.962356
≥1 USD $0.962356
≥200 USD $0.38468
≥500 USD $0.371551
≥1000 USD $0.364986
Inventory: 1595
Minimum: 1
-
+

Technical Details

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case SMD/SMT
Terminal Shape GULL WING
Dielectric Material Ceramic

Technical

Operating Temperature -25°C~85°C
Packaging Tape & Reel (TR)
Series TZB4
Size / Dimension 0.177Lx0.157W 4.50mmx4.00mm
Tolerance 50%
JESD-609 Code e3
Feature General Purpose
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin (Sn)
Additional Feature PERCENTAGE TOLERANCE ON C_MAX IS 0/+50
HTS Code 8532.30.00.10
Voltage - Rated DC 100V
Packing Method TR, 13 INCH
Depth 4.5mm
Capacitor Type VARIABLE CAPACITOR
Size Code 2816
Q @ Freq 500 @ 1MHz
Adjustment Type Bottom Adjustment
Capacitance Range 4.5pF~20pF
Adjuster Orientation VERTICAL

Dimensions

Height 2.9972mm
Height Seated (Max) 0.126 3.20mm
Length 7mm
Width 4mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
