TZB4R200BB10R01
RoHS
RoHS compliant
RoHS compliantPackage /
Category Capacitors / Trimmers, Variable Capacitors
Description
TZB4 VARIABLE CAPACITOR Trimmer Capacitor 0.177Lx0.157W 4.50mmx4.00mm 50% 4.5pF~20pF 100V
PDF
/
Buying Options
Total Price: USD $0.95
Unit Price: USD $0.947914
≥1 USD $0.947914
≥200 USD $0.378115
≥500 USD $0.366299
≥1000 USD $0.359735
Inventory: 7633
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Material Ceramic
Terminal Shape GULL WING
Mounting Type Surface Mount
Supply Chain
Lifecycle Status TO BE DISCONTINUED (Last Updated: 3 weeks ago)
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 4mm
Length 7mm
Height Seated (Max) 0.126 3.20mm
Height 2.9972mm
Technical
Adjuster Orientation VERTICAL
Capacitance Range 4.5pF~20pF
Adjustment Type Top
Q @ Freq 500 @ 1MHz
Size Code 2816
Capacitor Type VARIABLE CAPACITOR
Depth 4.5mm
Packing Method TR, 13 INCH
Voltage - Rated DC 100V
HTS Code 8532.30.00.10
Additional Feature PERCENTAGE TOLERANCE ON C_MAX IS 0/+50
Terminal Finish Tin (Sn)
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature General Purpose
JESD-609 Code e3
Tolerance 50%
Size / Dimension 0.177Lx0.157W 4.50mmx4.00mm
Series TZB4
Packaging Tape & Reel (TR)
Operating Temperature -25°C~85°C
