TZB4P300AB10R00
RoHS
/
Package B
Category Capacitors / Trimmers, Variable Capacitors
Description
B TZB4 100V 0F 50% 500ppm/C
PDF
/
Buying Options
Total Price: USD $47250
Unit Price: USD $1.89
≥25000 USD $1.89
Inventory: 30100
Minimum: 25000
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Height Seated (Max) 0.126 3.20mm
Height 3mm
Technical
Capacitance Range 6.5pF~30pF
Adjustment Type Top
Q @ Freq 300 @ 1MHz
Test Frequency 1MHz
Voltage 100V
Lead Pitch 2.7mm
Depth 4.5mm
Voltage - Rated DC 100V
Capacitance 0F
Color Green
Temperature Coefficient 500 ppm/°C
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature General Purpose
Tolerance 50%
Size / Dimension 0.177Lx0.157W 4.50mmx4.00mm
Series TZB4
Packaging Cut Tape (CT)
Operating Temperature -25°C~85°C
Physical
Dielectric Material Ceramic
Number of Pins 2
Package / Case B
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status TO BE DISCONTINUED (Last Updated: 2 weeks ago)
