47473R5
RoHS
RoHS compliant
RoHS compliantPackage /
Category Capacitors / Trimmers, Variable Capacitors
Description
Giga-Trim? VARIABLE CAPACITOR variable capacitor 0.150Dia 3.81mm 2pF~6pF 500V
PDF
/
Buying Options
Total Price: USD $35.47
Unit Price: USD $35.469306
≥1 USD $35.469306
≥200 USD $14.153062
≥400 USD $13.680418
≥800 USD $13.446722
Inventory: 9525
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type Surface Mount
Surface Mount YES
Terminal Shape GULL WING
Dielectric Material Alumina
Technical
Operating Temperature -65°C~125°C
Packaging Tape & Reel (TR)
Published 2007
Series Giga-Trim?
Size / Dimension 0.150Dia 3.81mm
JESD-609 Code e4
Feature General Purpose
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish GOLD/SILVER
Voltage - Rated 500V
HTS Code 8532.30.00.10
Packing Method TR
Capacitor Type VARIABLE CAPACITOR
Rated (DC) Voltage (URdc) 500V
Q @ Freq 1500 @ 213MHz
Adjustment Type Top
Capacitance Range 2pF~6pF
Adjuster Orientation VERTICAL
Multi-turn 1
Dimensions
Diameter 3.81mm
Height Seated (Max) 0.330 8.38mm
Length 8.38mm
Compliance
RoHS Status RoHS Compliant
