91ER2KLF
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Cermet TRIMMER VERTICAL SCREW Trimmer Potentiometer ±20% 0.5W 1/2W 70C 250V
PDF
/
Inventory: 8164
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 28 Weeks
Physical
Mounting Type Through Hole
Surface Mount NO
Terminal Shape WIRE
Resistive Material Cermet
Technical
Published 2006
Series 91
Size / Dimension Rectangular - 0.420 x 0.375 Face x 0.280 H 10.67mmx9.53mmx7.11mm
Tolerance ±20%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Number of Terminations 3
ECCN Code EAR99
Temperature Coefficient ±100ppm/°C
Resistance 2kOhm
Terminal Finish Matte Tin (Sn)
Power (Watts) 0.5W 1/2W
Additional Feature RATED AC VOLTAGE (V): 250
HTS Code 8533.40.80.50
Packing Method BULK
Construction Cylindrical
Resistor Type TRIMMER
Termination Style PC Pins
Rated Power Dissipation (P) 0.5W
Actuator Type SCREW
Operating Temperature (Min) -55°C
Lead Length 4.57mm
Working Voltage 250V
Lead Diameter 0.508 mm
Rated Temperature 70°C
Adjustment Type Top Adjustment
Number of Turns 1
Actuator Orientation VERTICAL
Ganging Number 1
Compliance
RoHS Status RoHS Compliant
