84XR100KLFTR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
TRIMMER 100K OHM 0.25W GW SIDE
PDF
/
Inventory: 2115
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Ganging Number 1
Rotation Angle 4320 deg
Actuator Orientation HORIZONTAL
Number of Turns 12
Adjustment Type Side Adjustment
Rated Temperature 85°C
Size Code 2517
Working Voltage 200V
Operating Temperature (Min) -65°C
Actuator Type SCREW
Operating Temperature (Max) 150°C
Rated Power Dissipation (P) 0.25W
Termination Style Gull Wing
Resistor Type TRIMMER
Construction Square
Packing Method TR, EMBOSSED, 13 INCH
Subcategory Variable Resistors
HTS Code 8533.40.80.50
Power (Watts) 0.25W 1/4W
Terminal Finish Matte Tin (Sn)
Resistance 100kOhm
Temperature Coefficient ±100ppm/°C
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Tolerance ±10%
Size / Dimension Rectangular - 0.290 x 0.250 Face x 0.295 H 7.37mmx6.35mmx7.49mm
Series 84
Published 2012
Packaging Tape & Reel (TR)
Physical
Resistive Material Cermet
Terminal Shape FLAT
Surface Mount YES
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
