82PR1MEGLFTB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Cermet TRIMMER VERTICAL SCREW Trimmer Potentiometer ±10% 220deg 0.5W 1/2W 70C
PDF
/
Inventory: 8220
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Through Hole
Surface Mount NO
Terminal Shape WIRE
Resistive Material Cermet
Technical
Series 82
Size / Dimension Round - 0.250Dia x 0.140 H 6.35mmx3.56mm
Tolerance ±10%
JESD-609 Code e3
Part Status Active
Number of Terminations 3
ECCN Code EAR99
Temperature Coefficient ±100ppm/°C
Resistance 1MOhm
Terminal Finish Matte Tin (Sn)
Power (Watts) 0.5W 1/2W
Additional Feature RATED AC VOLTAGE (V): 200
HTS Code 8533.40.80.50
Subcategory Variable Resistors
Packing Method TUBE
Construction Cylindrical
Resistor Type TRIMMER
Termination Style PC Pins
Rated Power Dissipation (P) 0.5W
Actuator Type SCREW
Operating Temperature (Min) -55°C
Lead Length 6.35mm
Working Voltage 200V
Lead Diameter 0.432 mm
Rated Temperature 70°C
Adjustment Type Top Adjustment
Number of Turns 1
Actuator Orientation VERTICAL
Rotation Angle 220 deg
Ganging Number 1
Compliance
RoHS Status RoHS Compliant
