78LR10KLF
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Cermet TRIMMER HORIZONTAL SCREW Trimmer Potentiometer ±10% 7920deg 1W 70C
PDF
/
Inventory: 6560
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Panel Mount, Wire Leads
Surface Mount NO
Terminal Shape FLEXIBLE WIRE
Mounting Feature CHASSIS MOUNT
Resistive Material Cermet
Technical
Published 2006
Series 78
Tolerance ±10%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Number of Terminations 3
ECCN Code EAR99
Temperature Coefficient ±100ppm/°C
Resistance 10kOhm
Terminal Finish Matte Tin (Sn)
Power (Watts) 1W
HTS Code 8533.40.80.50
Subcategory Variable Resistors
Packing Method BULK
Construction Rectangular
Resistor Type TRIMMER
Termination Style Wire Leads
Rated Power Dissipation (P) 1W
Operating Temperature (Max) 125°C
Actuator Type SCREW
Operating Temperature (Min) -55°C
Working Voltage 300V
Rated Temperature 70°C
Adjustment Type Side Adjustment
Number of Turns 22
Actuator Orientation HORIZONTAL
Rotation Angle 7920 deg
Ganging Number 1
Compliance
RoHS Status RoHS Compliant
