72PLR10KLF
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
TRIMMER 10K OHM 0.5W PC PIN TOP
PDF
/
Inventory: 3270
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Through Hole
Surface Mount NO
Terminal Shape WIRE
Resistive Material Cermet
Technical
Published 2006
Series 72
Size / Dimension Rectangular - 0.221 x 0.206 Face x 0.187 H 5.61mmx5.23mmx4.75mm
Tolerance ±10%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Number of Terminations 3
ECCN Code EAR99
Temperature Coefficient ±100ppm/°C
Resistance 10kOhm
Terminal Finish Matte Tin (Sn)
Power (Watts) 0.5W 1/2W
HTS Code 8533.40.80.50
Subcategory Variable Resistors
Packing Method BULK
Construction Trimmer Pot
Resistor Type TRIMMER
Termination Style PC Pins
Rated Power Dissipation (P) 0.5W
Actuator Type SCREW
Operating Temperature (Min) -55°C
Lead Length 4.6mm
Working Voltage 200V
Lead Diameter 0.53 mm
Size Code 3838
Rated Temperature 85°C
Adjustment Type Top Adjustment
Number of Turns 1
Actuator Orientation VERTICAL
Rotation Angle 244 deg
Compliance
RoHS Status RoHS Compliant
