64YFR50KLFAP
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
TRIMMER 50K OHM 0.25W PC PIN TOP
PDF
/
Inventory: 1398
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Ganging Number 1
Rotation Angle 4320 deg
Actuator Orientation VERTICAL
Number of Turns 12
Adjustment Type Top Adjustment
Rated Temperature 85°C
Lead Diameter 0.46 mm
Working Voltage 200V
Lead Length 15.24mm
Operating Temperature (Min) -65°C
Actuator Type SCREW
Operating Temperature (Max) 150°C
Rated Power Dissipation (P) 0.25W
Termination Style PC Pins
Resistor Type TRIMMER
Packing Method AMMO PACK
Subcategory Variable Resistors
HTS Code 8533.40.80.50
Additional Feature RATED AC VOLTAGE (V): 200
Power (Watts) 0.25W 1/4W
Resistance 50kOhm
Temperature Coefficient ±100ppm/°C
ECCN Code EAR99
Number of Terminations 3
Part Status Obsolete
Tolerance ±10%
Size / Dimension Rectangular - 0.250 x 0.165 Face x 0.270 H 6.35mmx4.19mmx6.86mm
Series 64
Physical
Resistive Material Cermet
Terminal Shape WIRE
Surface Mount NO
Mounting Type Through Hole
Supply Chain
Factory Lead Time 5 Weeks
