45JR200KLFT7
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Cermet TRIMMER HORIZONTAL SCREW Trimmer Potentiometer ±10% 0.25W 1/4W 85C 200kOhm
PDF
/
Inventory: 8382
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Actuator Orientation HORIZONTAL
Number of Turns 15
Adjustment Type Side Adjustment
Rated Temperature 85°C
Operating Temperature (Min) -65°C
Actuator Type SCREW
Rated Power Dissipation (P) 0.25W
Termination Style J Lead
Resistor Type TRIMMER
Packing Method TR, EMBOSSED, 7 INCH
HTS Code 8533.40.80.50
Power (Watts) 0.25W 1/4W
Terminal Finish Matte Tin (Sn)
Resistance 200kOhm
Temperature Coefficient ±100ppm/°C
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±10%
Size / Dimension Rectangular - 0.198 x 0.190 Face x 0.147 H 5.03mmx4.83mmx3.73mm
Series 45
Published 2010
Packaging Tape & Reel (TR)
Physical
Resistive Material Cermet
Terminal Shape WRAPAROUND
Surface Mount YES
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 14 Weeks
