44WR500KLFT13

TT Electronics/BI
RoHS
RoHS RoHS compliant
Package /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description TRIMMER 500KOHM 0.25W J LEAD TOP
PDF
/
Inventory: 4924
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 14 Weeks

Physical

Mounting Type Surface Mount
Surface Mount YES
Terminal Shape HOOK
Resistive Material Cermet

Technical

Packaging Tape & Reel (TR)
Series 44
Size / Dimension Rectangular - 0.190 x 0.154 Face x 0.209 H 4.83mmx3.91mmx5.31mm
Tolerance ±10%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Temperature Coefficient ±100ppm/°C
Resistance 500kOhm
Terminal Finish Matte Tin (Sn)
Power (Watts) 0.25W 1/4W
HTS Code 8533.40.80.50
Subcategory Variable Resistors
Packing Method TR, EMBOSSED, 13 INCH
Resistor Type TRIMMER
Termination Style J Lead
Rated Power Dissipation (P) 0.25W
Operating Temperature (Max) 150°C
Actuator Type SCREW
Operating Temperature (Min) -65°C
Working Voltage 300V
Rated Temperature 85°C
Adjustment Type Top Adjustment
Number of Turns 9
Actuator Orientation VERTICAL
Rotation Angle 3240 deg
Ganging Number 1

Compliance

RoHS Status RoHS Compliant
