44JR2KLFT13
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Cermet TRIMMER HORIZONTAL SCREW Trimmer Potentiometer ±10% 3240deg 0.25W 1/4W 85C
PDF
/
Inventory: 4344
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mounting Type Surface Mount
Surface Mount YES
Terminal Shape HOOK
Resistive Material Cermet
Technical
Packaging Tape & Reel (TR)
Published 2010
Series 44
Size / Dimension Rectangular - 0.198 x 0.190 Face x 0.147 H 5.03mmx4.83mmx3.73mm
Tolerance ±10%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Temperature Coefficient ±100ppm/°C
Resistance 2kOhm
Terminal Finish Matte Tin (Sn)
Power (Watts) 0.25W 1/4W
HTS Code 8533.40.80.50
Subcategory Variable Resistors
Packing Method TR, EMBOSSED, 13 INCH
Resistor Type TRIMMER
Ganging Number 1
Rotation Angle 3240 deg
Actuator Orientation HORIZONTAL
Number of Turns 9
Adjustment Type Side Adjustment
Rated Temperature 85°C
Working Voltage 300V
Operating Temperature (Min) -65°C
Actuator Type SCREW
Operating Temperature (Max) 150°C
Rated Power Dissipation (P) 0.25W
Termination Style Gull Wing
Compliance
RoHS Status RoHS Compliant
