44GR20KLFT7
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
TRIMMER 20K OHM 0.25W GW SIDE
PDF
/
Inventory: 4115
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mounting Type Surface Mount
Surface Mount YES
Resistive Material Cermet
Technical
Packaging Tape & Reel (TR)
Series 44
Size / Dimension Rectangular - 0.229 x 0.190 Face x 0.154 H 5.82mmx4.83mmx3.91mm
Tolerance ±10%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Temperature Coefficient ±100ppm/°C
Resistance 20kOhm
Terminal Finish Matte Tin (Sn)
Power (Watts) 0.25W 1/4W
HTS Code 8533.40.80.50
Subcategory Variable Resistors
Packing Method TR, EMBOSSED, 7 INCH
Resistor Type TRIMMER
Termination Style Gull Wing
Rated Power Dissipation (P) 0.25W
Operating Temperature (Max) 150°C
Actuator Type SCREW
Operating Temperature (Min) -65°C
Working Voltage 300V
Rated Temperature 85°C
Adjustment Type Side Adjustment
Number of Turns 9
Actuator Orientation HORIZONTAL
Rotation Angle 3240 deg
Ganging Number 1
Compliance
RoHS Status RoHS Compliant
