25XR20LF
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
TRIMMER 20 OHM 0.5W PC PIN SIDE
PDF
/
Inventory: 1416
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type Through Hole
Surface Mount NO
Terminal Shape FLAT
Resistive Material Cermet
Technical
Published 2011
Series 25
Tolerance ±10%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 3
ECCN Code EAR99
Temperature Coefficient ±100ppm/°C
Resistance 20Ohm
Terminal Finish Matte Tin (Sn)
Power (Watts) 0.5W 1/2W
Additional Feature RATED AC VOLTAGE (V): 300
HTS Code 8533.40.80.50
Subcategory Variable Resistors
Packing Method TUBE
Construction Rectangular
Resistor Type TRIMMER
Termination Style PC Pins
Rated Power Dissipation (P) 0.5W
Actuator Type SCREW
Operating Temperature (Min) -55°C
Lead Length 5.08mm
Working Voltage 300V
Rated Temperature 70°C
Adjustment Type Side Adjustment
Number of Turns 1
Actuator Orientation HORIZONTAL
Ganging Number 1
Compliance
RoHS Status RoHS Compliant
