EVM-3WSX80B55
RoHS
/
Package /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
TRIMMER 500KOHM 0.15W J LEAD TOP
PDF
/
Buying Options
Total Price: USD $0.44
Unit Price: USD $0.437196
≥1 USD $0.437196
≥200 USD $0.174616
≥500 USD $0.169364
≥1000 USD $0.166738
Inventory: 1136
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Height 939.8μm
Technical
Rotation Angle 240 deg
Actuator Orientation VERTICAL
Number of Turns 1
Adjustment Type Top Adjustment
Working Voltage 50V
Actuator Type SCREW
Termination Style J Lead
Resistor Type TRIMMER
Construction Trimmer
Depth 3.75mm
Max Power Dissipation 150mW
Packing Method TR, 7 INCH
Power Rating 150mW
Subcategory POTENTIOMETER
HTS Code 8533.40.80.50
Power (Watts) 0.15W
Color Silver
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Resistance 500kOhm
Temperature Coefficient ±250ppm/°C
ECCN Code EAR99
Termination Foot Print
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Tolerance ±25%
Size / Dimension Rectangular - 0.136 x 0.122 Face x 0.037 H 3.45mmx3.10mmx0.95mm
Series EVM
Published 2011
Packaging Tape & Reel (TR)
Physical
Resistive Material Cermet
Terminal Shape WRAPAROUND
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 17 Weeks
