EVM-3WSW80BQ2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Cermet TRIMMER VERTICAL SCREW Trimmer Potentiometer ±25% 240deg 0.15W -40C
PDF
/
Inventory: 4017
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Rotation Angle 240 deg
Actuator Orientation VERTICAL
Number of Turns 1
Adjustment Type Top Adjustment
Working Voltage 50V
Operating Temperature (Min) -40°C
Actuator Type SCREW
Termination Style Surface Mount
Reach Compliance Code compliant
Resistor Type TRIMMER
Construction Trimmer
Packing Method TR, 7 INCH
Subcategory Variable Resistors
HTS Code 8533.40.80.50
Power (Watts) 0.15W
Resistance 470Ohm
Temperature Coefficient ±250ppm/°C
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Tolerance ±25%
Series EVM
Published 2017
Packaging Tape & Reel (TR)
Physical
Resistive Material Cermet
Terminal Shape WRAPAROUND
Surface Mount YES
Mounting Type Surface Mount
