EVM-3VSX50BY4
RoHS
/
Package /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Cermet TRIMMER VERTICAL SCREW Trimmer Potentiometer ±25% 240deg 150mW 100C
PDF
/
Inventory: 6874
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Terminal Shape WRAPAROUND
Resistive Material Cermet
Technical
Packaging Tape & Reel (TR)
Published 2017
Series EVM
Tolerance ±25%
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Termination Foot Print
ECCN Code EAR99
Temperature Coefficient ±250ppm/°C
Resistance 33kOhm
Max Operating Temperature 100°C
Min Operating Temperature -40°C
Power (Watts) 0.15W
HTS Code 8533.40.80.50
Subcategory POTENTIOMETER
Power Rating 150mW
Packing Method TR, 7 INCH
Construction Trimmer
Resistor Type TRIMMER
Termination Style Surface Mount
Actuator Type SCREW
Working Voltage 50V
Adjustment Type Top Adjustment
Number of Turns 1
Actuator Orientation VERTICAL
Rotation Angle 240 deg
Dimensions
Length 3.1mm
Compliance
RoHS Status RoHS Compliant
