EVM-3VSX50B24
RoHS
/
Package /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Res Cermet Trimmer 20K Ohm 25% 0.15W 1Turn (3.1 X 3.75 X 1.4mm) Foot Print SMD Carrier T/R
PDF
/
Inventory: 5172
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Terminal Shape WRAPAROUND
Resistive Material Cermet
Technical
Packaging Tape & Reel (TR)
Published 2006
Series EVM
Size / Dimension Rectangular - 0.136 x 0.122 Face x 0.055 H 3.45mmx3.10mmx1.40mm
Tolerance ±25%
JESD-609 Code e3/e4
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Termination Foot Print
ECCN Code EAR99
Temperature Coefficient ±250ppm/°C
Resistance 20kOhm
Color Silver
Power (Watts) 0.15W
HTS Code 8533.40.80.50
Subcategory POTENTIOMETER
Power Rating 150mW
Packing Method TR, 7 INCH
Max Power Dissipation 150mW
Depth 3.75mm
Construction Trimmer
Resistor Type TRIMMER
Military Standard Not
Termination Style J Lead
Actuator Type SCREW
Operating Temperature (Min) -40°C
Working Voltage 50V
Adjustment Type Top Adjustment
Number of Turns 1
Actuator Orientation VERTICAL
Rotation Angle 240 deg
Dimensions
Height 1.397mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
