EVM-3SSX50BY2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Cermet TRIMMER VERTICAL SCREW trimmer potentiometer ±25% 260deg 0.15W -40C
PDF
/
Inventory: 1436
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Surface Mount YES
Terminal Shape WRAPAROUND
Resistive Material Cermet
Technical
Packaging Tape & Reel (TR)
Published 2017
Series EVM
Size / Dimension Rectangular - 0.148 x 0.118 Face x 0.055 H 3.75mmx3.00mmx1.40mm
Tolerance ±25%
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Temperature Coefficient ±250ppm/°C
Resistance 330Ohm
Power (Watts) 0.15W
HTS Code 8533.40.80.50
Subcategory POTENTIOMETER
Packing Method TR, 7 INCH
Construction Trimmer
Resistor Type TRIMMER
Reach Compliance Code compliant
Termination Style J Lead
Actuator Type SCREW
Operating Temperature (Min) -40°C
Working Voltage 50V
Adjustment Type Top and Bottom Adjustment
Number of Turns 1
Actuator Orientation VERTICAL
Rotation Angle 260 deg
Compliance
RoHS Status RoHS Compliant
