EVM-3RSX50B25
RoHS
/
Package /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Cermet TRIMMER VERTICAL SCREW Trimmer Potentiometer ±25% 260deg 150mW -40C
PDF
/
Inventory: 8298
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Height 1.397mm
Technical
Rotation Angle 260 deg
Actuator Orientation VERTICAL
Number of Turns 1
Adjustment Type Bottom Adjustment
Working Voltage 50V
Operating Temperature (Min) -40°C
Actuator Type SCREW
Termination Style J Lead
Resistor Type TRIMMER
Construction Trimmer
Max Power Dissipation 150mW
Packing Method TR, 7 INCH
Power Rating 150mW
Subcategory POTENTIOMETER
HTS Code 8533.40.80.50
Power (Watts) 0.15W
Color Silver
Resistance 200kOhm
Temperature Coefficient ±250ppm/°C
ECCN Code EAR99
Termination Foot Print
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Tolerance ±25%
Size / Dimension Rectangular - 0.136 x 0.122 Face x 0.055 H 3.45mmx3.10mmx1.40mm
Series EVM
Published 2011
Packaging Tape & Reel (TR)
Physical
Resistive Material Cermet
Terminal Shape WRAPAROUND
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 17 Weeks
