EVM-1DSX30BQ2
RoHS
/
Package /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Res Cermet Trimmer 470 Ohm 25% 0.2W(1/5W) 1(Elec)/1(Mech)Turn (3.8 X 4.5 X 1.4mm) Foot Print SMD Carrier T/R
PDF
/
Buying Options
Total Price: USD $0.55
Unit Price: USD $0.554044
≥1 USD $0.554044
≥200 USD $0.22188
≥500 USD $0.214003
≥1000 USD $0.210064
Inventory: 5994
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Terminal Shape WRAPAROUND
Resistive Material Cermet
Technical
Packaging Tape & Reel (TR)
Published 2010
Series EVM
Size / Dimension Rectangular - 0.177 x 0.150 Face x 0.055 H 4.50mmx3.80mmx1.40mm
Tolerance ±25%
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Termination Foot Print
ECCN Code EAR99
Temperature Coefficient ±250ppm/°C
Resistance 470Ohm
Power (Watts) 0.2W 1/5W
HTS Code 8533.40.80.50
Subcategory POTENTIOMETER
Packing Method TR, 7 INCH
Depth 4.5mm
Construction Trimmer
Resistor Type TRIMMER
Military Standard Not
Termination Style Surface Mount
Rated Power Dissipation (P) 0.2W
Actuator Type SCREW
Operating Temperature (Min) -40°C
Working Voltage 50V
Adjustment Type Top Adjustment
Number of Turns 1
Actuator Orientation VERTICAL
Rotation Angle 260 deg
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
