EVM-1DSX30BC5
RoHS
/
Package /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Cermet TRIMMER VERTICAL SCREW Trimmer Potentiometer ±25% 260deg 0.2W 1/5W -40C
PDF
/
Inventory: 1558
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Terminal Shape WRAPAROUND
Resistive Material Cermet
Technical
Packaging Tape & Reel (TR)
Published 2017
Series EVM
Size / Dimension Rectangular - 0.177 x 0.150 Face x 0.055 H 4.50mmx3.80mmx1.40mm
Tolerance ±25%
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Temperature Coefficient ±250ppm/°C
Resistance 150kOhm
Power (Watts) 0.2W 1/5W
HTS Code 8533.40.80.50
Subcategory POTENTIOMETER
Packing Method TR, 7 INCH
Construction Trimmer
Resistor Type TRIMMER
Termination Style Surface Mount
Rated Power Dissipation (P) 0.2W
Actuator Type SCREW
Operating Temperature (Min) -40°C
Working Voltage 50V
Adjustment Type Top Adjustment
Number of Turns 1
Actuator Orientation VERTICAL
Rotation Angle 260 deg
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
