TM7EX503
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Cermet Active Blue ROHS3Compliant Trimmer Potentiometer ±10% 500mW 120C 50kOhms
PDF
/
Inventory: 2862
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 690mg
Resistive Material Cermet
Technical
Packaging Bulk
Published 2012
Series TM-7
Size / Dimension Square - 0.323Lx0.283W x 0.331 H 8.20mmx7.20mmx8.40mm
Tolerance ±10%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Temperature Coefficient ±100ppm/°C
Resistance 50kOhms
Max Operating Temperature 120°C
Min Operating Temperature -55°C
Composition Cermet
Color Blue
Power (Watts) 0.5W 1/2W
Max Power Dissipation 500mW
Termination Style PC Pins
Adjustment Type Side Adjustment
Number of Turns 3
Dimensions
Diameter 7.2mm
Height 8.4074mm
Length 8.2042mm
Width 7.1882mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
