Package /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description Cermet Active Blue ROHS3Compliant Trimmer Potentiometer ±10% 500mW 120C 2kOhms
PDF
/
Inventory: 2801
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Weight 690mg
Resistive Material Cermet
Mounting Type Through Hole
Mount Through Hole

Technical

Packaging Bulk
Published 2012
Series TM-7
Size / Dimension Square - 0.323Lx0.283W x 0.331 H 8.20mmx7.20mmx8.40mm
Tolerance ±10%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Temperature Coefficient ±100ppm/°C
Resistance 2kOhms
Max Operating Temperature 120°C
Min Operating Temperature -55°C
Composition Cermet
Color Blue
Power (Watts) 0.5W 1/2W
Max Power Dissipation 500mW
Termination Style PC Pins
Adjustment Type Side Adjustment
Number of Turns 3

Dimensions

Diameter 7.2mm
Height 8.4074mm
Length 8.2042mm
Width 7.1882mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free

Supply Chain

Factory Lead Time 9 Weeks
