TM7ES104
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Cermet Active Blue ROHS3Compliant trimmer potentiometer ±10% 500mW 120C 100kOhms
PDF
/
Inventory: 9008
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 7.1882mm
Length 8.2042mm
Height 8.4074mm
Diameter 7.2mm
Technical
Number of Turns 3
Adjustment Type Side Adjustment
Termination Style PC Pins
Max Power Dissipation 500mW
Power (Watts) 0.5W 1/2W
Color Blue
Composition Cermet
Min Operating Temperature -55°C
Max Operating Temperature 120°C
Resistance 100kOhms
Temperature Coefficient ±100ppm/°C
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±10%
Size / Dimension Square - 0.323Lx0.283W x 0.331 H 8.20mmx7.20mmx8.40mm
Series TM-7
Published 2012
Packaging Bulk
Physical
Resistive Material Cermet
Weight 690mg
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
