ST5ETR504
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Cermet Active Black ROHS3Compliant trimmer potentiometer ±10% 250mW 120C 500kOhms
PDF
/
Inventory: 6500
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Weight 350mg
Resistive Material Cermet
Technical
Packaging Tape & Reel (TR)
Published 2006
Series ST5
Size / Dimension Square - 0.266Lx0.236W x 0.169 H 6.75mmx6.00mmx4.30mm
Tolerance ±10%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Gull Wing
Temperature Coefficient ±100ppm/°C
Resistance 500kOhms
Max Operating Temperature 120°C
Min Operating Temperature -55°C
Composition Cermet
Color Black
Power (Watts) 0.25W 1/4W
Max Power Dissipation 250mW
Termination Style Gull Wing
Adjustment Type Side Adjustment
Number of Turns 14
Dimensions
Height 4.2926mm
Length 6.7564mm
Width 5.9944mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
