ST4ETH104
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Cermet Active Black ROHS3Compliant Trimmer Potentiometer ±20% 250mW 125C 100kOhms
PDF
/
Inventory: 9061
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Weight 220mg
Resistive Material Cermet
Technical
Packaging Tape & Reel (TR)
Published 2014
Series ST4
Size / Dimension Square - 0.197Lx0.177W x 0.224 H 5.00mmx4.50mmx5.70mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Gull Wing
Temperature Coefficient ±100ppm/°C
Resistance 100kOhms
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Composition Cermet
Color Black
Power (Watts) 0.25W 1/4W
Max Power Dissipation 250mW
Termination Style Gull Wing
Adjustment Type Side Adjustment
Number of Turns 1
Dimensions
Height 5.6896mm
Length 5.0038mm
Width 4.4958mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
