ST42ETB105
RoHS
RoHS compliant
RoHS compliantPackage SMD/SMT
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Cermet Active Black ROHS3Compliant Trimmer Potentiometer ±20% 250mW 125C 1MOhms
PDF
/
Inventory: 9836
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 4.4958mm
Length 5.0038mm
Height 2.3114mm
Technical
Number of Turns 1
Adjustment Type Top Adjustment
Termination Style Gull Wing
Max Power Dissipation 250mW
Power (Watts) 0.25W 1/4W
Color Black
Composition Cermet
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Resistance 1MOhms
Temperature Coefficient ±100ppm/°C
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension Square - 0.197Lx0.177W x 0.091 H 5.00mmx4.50mmx2.30mm
Series ST42
Published 2006
Packaging Tape & Reel (TR)
Physical
Resistive Material Cermet
Weight 120mg
Package / Case SMD/SMT
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 9 Weeks
