SM-43TX504
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Cermet Active ROHS3Compliant Gull Wing Trimmer Potentiometer ±10% 250mW 150C 500kOhms
PDF
/
Inventory: 5447
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 3.5052mm
Length 4.8006mm
Height 5.1054mm
Technical
Number of Turns 5
Adjustment Type Top Adjustment
Termination Style Gull Wing
Max Power Dissipation 250mW
Power (Watts) 0.25W 1/4W
Composition Cermet
Min Operating Temperature -65°C
Max Operating Temperature 150°C
Resistance 500kOhms
Temperature Coefficient ±100ppm/°C
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±10%
Size / Dimension Square - 0.189Lx0.138W x 0.201 H 4.80mmx3.50mmx5.10mm
Series SM43
Published 2012
Packaging Tape & Reel (TR)
Physical
Resistive Material Cermet
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 9 Weeks
