Package /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description Cermet Active ROHS3Compliant Gull Wing Trimmer Potentiometer ±10% 250mW 150C 500kOhms
PDF
/
Inventory: 2375
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Width 4.5974mm
Length 4.8006mm
Height 3.9116mm

Technical

Number of Turns 5
Adjustment Type Side Adjustment
Termination Style Gull Wing
Max Power Dissipation 250mW
Power (Watts) 0.25W 1/4W
Composition Cermet
Min Operating Temperature -65°C
Max Operating Temperature 150°C
Resistance 500kOhms
Temperature Coefficient ±100ppm/°C
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±10%
Size / Dimension Square - 0.189Lx0.181W x 0.154 H 4.80mmx4.60mmx3.90mm
Series SM43
Published 2012
Packaging Tape & Reel (TR)

Physical

Resistive Material Cermet
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 9 Weeks
