SM-43TA201
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Cermet Active ROHS3Compliant J Lead Trimmer Potentiometer ±10% 250mW 150C 200Ohms
PDF
/
Inventory: 1617
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Resistive Material Cermet
Technical
Packaging Tape & Reel (TR)
Published 2012
Series SM43
Size / Dimension Square - 0.189Lx0.181W x 0.146 H 4.80mmx4.60mmx3.70mm
Tolerance ±10%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Temperature Coefficient ±100ppm/°C
Resistance 200Ohms
Max Operating Temperature 150°C
Min Operating Temperature -65°C
Composition Cermet
Power (Watts) 0.25W 1/4W
Max Power Dissipation 250mW
Termination Style J Lead
Adjustment Type Side Adjustment
Number of Turns 5
Dimensions
Height 3.7084mm
Length 4.8006mm
Width 4.5974mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
