SM-42TX503
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
TRIMMER 50K OHM 0.25W SMD
PDF
/
Buying Options
Total Price: USD $3.9
Unit Price: USD $3.8984
≥1 USD $3.8984
≥10 USD $3.40912
≥100 USD $3.044096
≥500 USD $2.861408
≥1000 USD $2.8006
Inventory: 623
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Resistive Material Cermet
Technical
Packaging Tape & Reel (TR)
Published 2011
Series SM42
Size / Dimension Square - 0.189Lx0.138W x 0.201 H 4.80mmx3.50mmx5.10mm
Tolerance ±10%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Gull Wing
Temperature Coefficient ±100ppm/°C
Resistance 50kOhms
Max Operating Temperature 150°C
Min Operating Temperature -65°C
Composition Cermet
Power (Watts) 0.25W 1/4W
Power Rating 250mW
Max Power Dissipation 250mW
Termination Style Gull Wing
Adjustment Type Top Adjustment
Number of Turns 11
Dimensions
Height 5.1054mm
Length 4.8006mm
Width 3.5052mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
