SM-42TW105
RoHS
RoHS compliant
RoHS compliantPackage SMD/SMT
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
TRIMMER 1M OHM 0.25W SMD
PDF
/
Buying Options
Total Price: USD $3.9
Unit Price: USD $3.8984
≥1 USD $3.8984
≥10 USD $3.40912
≥100 USD $3.044096
≥500 USD $2.861408
≥1000 USD $2.8006
Inventory: 540
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 3.5052mm
Length 4.8006mm
Height 5.1054mm
Technical
Number of Turns 11
Adjustment Type Top Adjustment
Termination Style J Lead
Max Power Dissipation 250mW
Power Rating 250mW
Power (Watts) 0.25W 1/4W
Composition Cermet
Min Operating Temperature -65°C
Max Operating Temperature 150°C
Resistance 1MOhms
Temperature Coefficient ±100ppm/°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±10%
Size / Dimension Square - 0.189Lx0.138W x 0.201 H 4.80mmx3.50mmx5.10mm
Series SM42
Published 2011
Packaging Tape & Reel (TR)
Physical
Resistive Material Cermet
Package / Case SMD/SMT
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 9 Weeks
