SM-42TB503
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Cermet Active ROHS3Compliant Gull Wing Trimmer Potentiometer ±10% 250mW 150C 50kOhms
PDF
/
Inventory: 6329
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 4.5974mm
Length 4.8006mm
Height 3.9116mm
Technical
Number of Turns 11
Adjustment Type Side Adjustment
Termination Style Gull Wing
Max Power Dissipation 250mW
Power (Watts) 0.25W 1/4W
Composition Cermet
Min Operating Temperature -65°C
Max Operating Temperature 150°C
Resistance 50kOhms
Temperature Coefficient ±100ppm/°C
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±10%
Size / Dimension Square - 0.189Lx0.181W x 0.154 H 4.80mmx4.60mmx3.90mm
Series SM42
Published 2012
Packaging Tape & Reel (TR)
Physical
Resistive Material Cermet
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 9 Weeks
