SM-3TW105
RoHS
RoHS compliant
RoHS compliantPackage SMD/SMT
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Cermet Active ROHS3Compliant J Lead trimmer potentiometer ±20% 125mW 150C 1MOhms
PDF
/
Buying Options
Total Price: USD $21.05
Unit Price: USD $21.0463
≥1 USD $21.0463
≥10 USD $17.2691
≥100 USD $16.7295
≥500 USD $16.1899
≥1000 USD $15.6503
Inventory: 5309
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SMD/SMT
Resistive Material Cermet
Technical
Packaging Tape & Reel (TR)
Published 2012
Series SM3
Size / Dimension Rectangular - 0.154 x 0.126 Face x 0.154 H 3.90mmx3.20mmx3.90mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Temperature Coefficient ±100ppm/°C
Resistance 1MOhms
Max Operating Temperature 150°C
Min Operating Temperature -65°C
Composition Cermet
Power (Watts) 0.125W 1/8W
Max Power Dissipation 125mW
Termination Style J Lead
Adjustment Type Top Adjustment
Number of Turns 11
Dimensions
Height 3.9116mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
