SM-3TA201
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Cermet Active ROHS3Compliant J Lead Trimmer Potentiometer ±20% 125mW 150C 200Ohms
PDF
/
Inventory: 1578
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Resistive Material Cermet
Technical
Packaging Tape & Reel (TR)
Published 2012
Series SM3
Size / Dimension Square - 0.154 x 0.154 Face x 0.134 H 3.90mmx3.90mmx3.40mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Temperature Coefficient ±100ppm/°C
Resistance 200Ohms
Max Operating Temperature 150°C
Min Operating Temperature -65°C
Composition Cermet
Power (Watts) 0.125W 1/8W
Max Power Dissipation 125mW
Termination Style J Lead
Number of Turns 11
Adjustment Type Side Adjustment
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 3.4036mm
