RJ6S505
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Cermet Active Yellow ROHS3Compliant Trimmer Potentiometer ±10% 500mW 120C 5MOhms
PDF
/
Inventory: 6253
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 800mg
Resistive Material Cermet
Technical
Packaging Bulk
Published 2012
Series RJ-6
Size / Dimension Square - 0.276Lx0.260W x 0.343 H 7.00mmx6.60mmx8.70mm
Tolerance ±10%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Temperature Coefficient ±250ppm/°C
Resistance 5MOhms
Max Operating Temperature 120°C
Min Operating Temperature -55°C
Composition Cermet
Color Yellow
Power (Watts) 0.5W 1/2W
Max Power Dissipation 500mW
Termination Style PC Pins
Adjustment Type Side Adjustment
Number of Turns 1
Dimensions
Diameter 7mm
Height 8.7122mm
Length 7.0104mm
Width 6.604mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
