RJ6F505
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Cermet Active Yellow ROHS3Compliant trimmer potentiometer ±10% 500mW 120C 5MOhms
PDF
/
Buying Options
Total Price: USD $3.19
Unit Price: USD $3.190667
≥1 USD $3.190667
≥10 USD $3.010061
≥100 USD $2.839683
≥500 USD $2.678947
≥1000 USD $2.527309
Inventory: 1188
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 7.5946mm
Diameter 10.5mm
Technical
Number of Turns 1
Adjustment Type Bottom Adjustment
Termination Style PC Pins
Max Power Dissipation 500mW
Power (Watts) 0.5W 1/2W
Color Yellow
Composition Cermet
Min Operating Temperature -55°C
Max Operating Temperature 120°C
Resistance 5MOhms
Temperature Coefficient ±250ppm/°C
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±10%
Size / Dimension Round - 0.413Dia x 0.299 H 10.50mmx7.60mm
Series RJ-6
Published 2016
Packaging Bulk
Physical
Resistive Material Cermet
Weight 1.01g
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
