RJ5EX503
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Cermet Active Yellow ROHS3Compliant Trimmer Potentiometer ±10% 250mW 120C 50kOhms
PDF
/
Inventory: 1452
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 370mg
Resistive Material Cermet
Technical
Packaging Bulk
Published 2012
Series RJ-5
Size / Dimension Square - 0.236Lx0.169W x 0.266 H 6.00mmx4.30mmx6.75mm
Tolerance ±10%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Temperature Coefficient ±100ppm/°C
Resistance 50kOhms
Max Operating Temperature 120°C
Min Operating Temperature -55°C
Composition Cermet
Color Yellow
Power (Watts) 0.25W 1/4W
Max Power Dissipation 250mW
Termination Style PC Pins
Adjustment Type Side Adjustment
Number of Turns 14
Dimensions
Height 6.7564mm
Length 5.9944mm
Width 4.2926mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
