RJ13S502
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
TRIMMER 5K OHM 0.75W PC PIN SIDE
PDF
/
Inventory: 5047
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 12.4968mm
Length 13.589mm
Height 8.7884mm
Diameter 12.5mm
Technical
Number of Turns 1
Adjustment Type Side Adjustment
Termination Style PC Pins
Max Power Dissipation 750mW
Power (Watts) 0.75W 3/4W
Color Yellow
Composition Cermet
Min Operating Temperature -55°C
Max Operating Temperature 120°C
Resistance 5kOhms
Temperature Coefficient ±100ppm/°C
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±10%
Size / Dimension Square - 0.535Lx0.492W x 0.346 H 13.60mmx12.50mmx8.80mm
Series RJ-13
Published 2016
Packaging Bulk
Physical
Resistive Material Cermet
Weight 2.5g
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
