RJ13PR501
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Cermet Active Yellow ROHS3Compliant Trimmer Potentiometer ±10% 750mW 120C 500Ohms
PDF
/
Inventory: 8588
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 6.2992mm
Diameter 12.4mm
Technical
Number of Turns 1
Adjustment Type Top Adjustment
Termination Style PC Pins
Max Power Dissipation 750mW
Power (Watts) 0.75W 3/4W
Color Yellow
Composition Cermet
Min Operating Temperature -55°C
Max Operating Temperature 120°C
Resistance 500Ohms
Temperature Coefficient ±100ppm/°C
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±10%
Size / Dimension Round - 0.488Dia x 0.248 H 12.40mmx6.30mm
Series RJ-13
Published 2006
Packaging Bulk
Physical
Resistive Material Cermet
Weight 2.15g
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
