FT63EX201
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Cermet Active White ROHS3Compliant Trimmer Potentiometer ±10% 500mW 125C 200Ohms
PDF
/
Inventory: 7084
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 660mg
Resistive Material Cermet
Technical
Packaging Bulk
Published 2012
Series FT-63
Size / Dimension Rectangular - 0.323 x 0.276 Facex0.276L 8.20mmx7.00mmx7.00mm
Tolerance ±10%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Temperature Coefficient ±100ppm/°C
Resistance 200Ohms
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Composition Cermet
Color White
Power (Watts) 0.5W 1/2W
Max Power Dissipation 500mW
Termination Style PC Pins
Adjustment Type Side Adjustment
Number of Turns 1
Dimensions
Length 7.0104mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
