CT20EP502
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Cermet Active Blue ROHS3Compliant Trimmer Potentiometer ±10% 500mW 120C 5kOhms
PDF
/
Inventory: 3980
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 18.9992mm
Technical
Number of Turns 15
Adjustment Type Side Adjustment
Termination Style PC Pins
Max Power Dissipation 500mW
Power (Watts) 0.5W 1/2W
Color Blue
Composition Cermet
Min Operating Temperature -55°C
Max Operating Temperature 120°C
Resistance 5kOhms
Temperature Coefficient ±100ppm/°C
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±10%
Size / Dimension Rectangular - 0.252 x 0.197 Facex0.748L 6.40mmx5.00mmx19.00mm
Series CT20
Published 2004
Packaging Bulk
Physical
Resistive Material Cermet
Weight 1.08g
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Factory Lead Time 9 Weeks
