TC33X-2-201E
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Cermet Not TRIMMER VERTICAL Trimmer Potentiometer ±25% 100mW 70C 50V
PDF
/
Buying Options
Total Price: USD $0.25
Unit Price: USD $0.2464
≥1 USD $0.2464
≥10 USD $0.24024
≥100 USD $0.21648
≥500 USD $0.206624
≥1000 USD $0.199936
≥3000 USD $0.18663
Inventory: 1301
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 1.1938mm
Technical
Actuator Orientation VERTICAL
Number of Turns 1
Adjustment Type Top Adjustment
Rated Temperature 70°C
Working Voltage 50V
Actuator Type SCREW
Termination Style J Lead
Military Standard Not
Base Part Number TC33X
Resistor Type TRIMMER
Construction Trimmer Pot
Depth 3.8mm
Max Power Dissipation 100mW
Packing Method TR, EMBOSSED, 7 INCH
Power Rating 100mW
HTS Code 8533.40.80.50
Power (Watts) 0.1W 1/10W
Composition Cermet, Potentiometer
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Terminal Finish Matte Tin (Sn)
Resistance 200Ohm
Temperature Coefficient ±250ppm/°C
ECCN Code EAR99
Termination Foot Print
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±25%
Size / Dimension Rectangular - 0.150 x 0.142 Face x 0.047 H 3.80mmx3.60mmx1.20mm
Series Trimpot? TC33 - Open Frame
Published 2006
Packaging Tape & Reel (TR)
Physical
Resistive Material Cermet
Terminal Shape WRAPAROUND
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 18 Weeks
