RT24C2P200
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Res Wirewound Trimmer 20 Ohm 5% 0.75W(3/4W) 25(Elec)Turn 1.52mm (9.53 X 10.55 X 3.81mm) Pin Thru-Hole Tube
PDF
/
Inventory: 1967
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Surface Mount NO
Resistive Material Wirewound
Technical
Packaging Tube
Published 2010
Series Trimpot? RT24/RTR24-Sealed
Size / Dimension Rectangular - 0.375 x 0.150 Face x 0.150 H 9.53mmx3.81mmx3.81mm
Tolerance ±5%
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Termination Pin
ECCN Code EAR99
Temperature Coefficient ±50ppm/°C
Resistance 20Ohm
Max Operating Temperature 150°C
Min Operating Temperature -65°C
Power (Watts) 0.75W 3/4W
HTS Code 8533.31.00.00
Subcategory POTENTIOMETER
Technology WIRE WOUND
Depth 10.55mm
Construction Trimmer Pot
Resistor Type TRIMMER
Base Part Number RT24C2
Military Standard MIL-PRF-27208
Termination Style PC Pins
Rated Power Dissipation (P) 0.75W
Actuator Type SCREW
Lead Length 8mm
Lead Diameter 0.51 mm
Size Code 3838
Rated Temperature 85°C
Adjustment Type Side Adjustment
Number of Turns 25
Actuator Orientation HORIZONTAL
Rotation Angle 9000 deg
Compliance
RoHS Status ROHS3 Compliant
