RT22C2X101
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description
Res Wirewound Trimmer 100 Ohm 5% 3/4W 25(Elec)Turn 1.91mm (13.59 X 5.59 X 12.7mm) Pin Thru-Hole Tube
PDF
/
Inventory: 3026
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Through Hole
Mounting Type Chassis Mount
Weight 1.7g
Resistive Material Wirewound
Technical
Packaging Tube
Published 2007
Series Trimpot? RT22/RTR22-Sealed
Size / Dimension Rectangular - 0.500 x 0.220 Face x 0.500 H 12.70mmx5.59mmx12.70mm
Tolerance ±5%
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Termination Pin
Temperature Coefficient ±50ppm/°C
Resistance 100Ohm
Max Operating Temperature 150°C
Min Operating Temperature -65°C
Power (Watts) 0.75W 3/4W
Technology WIRE WOUND
Construction Square
Resistor Type TRIMMER
Base Part Number RT22C2
Military Standard MIL-PRF-27208
Termination Style PC Pins
Rated Power Dissipation (P) 0.75W
Actuator Type SCREW
Lead Length 6.35mm
Lead Diameter 0.71 mm
Rated Temperature 85°C
Adjustment Type Side Adjustment
Number of Turns 25
Actuator Orientation HORIZONTAL
Rotation Angle 9000 deg
Ganging Number 1
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
